Maximus Severe Duty™

Ruggedized Time Clock by Accu-Time Systems. Built tough for Extreme Environments

The new and improved Maximus Severe Duty™ Employee ruggedized time clock allows for integration with Workday Time Tracking and many time and attendance software applications. The state-of-the-art workforce management Severe Duty time and attendance time clock features environmentally sealed protection with a NEMA 4X rated enclosure and IP65 certification.

The Maximus Severe Duty ruggedized time clock is designed for those who demand a feature-rich terminal that works in harsh environments. All of our terminals feature cutting-edge technology: Web services, open standards, complete field upgradeability, keypad and function customization, varied auto-ID readers, optional Java™/Python programmability, and more!

  • IP65 certification
  • NEMA 4X rated enclosure
  • Water tight and dust tight
  • Environmentally sealed
  • Internet appliance
  • Eight programmable function keys
  • On-board diagnostics
  • Field-upgradeable
  • Optional Java™/Python programmable
  • Optional power-over-Ethernet module

Maximus Severe Duty Time Clock  Specifications

DISPLAY
  • 3.5” – 4:3
  • 320x 240
  • 18bit TFT Color
  • Non-touch Display
KEYPAD
  • 20-key tactile
    • Numeric keypad 0-9
    • Eight software-defined function keys
    • Keys, Clear/Enter keys
  • Customizable cover with your brand on the terminal
PROCESSOR
  • IMX28 – 454MHZ
MEMORY
  • 512MB NAND FLASH / 256 MB DDR2 RAM
MASS STORAGE
  • 8GB eMMC for CM/Recovery OS Programming
ETHERNET
  • Standard 10/100 BASE-T Ethernet
  • DHCP / IPV4 / IPv6 & Static IP
  • 2 USB 2.0 USB Type A Connectors
OPERATING SYSTEM
  • OS – Linux
PROGRAMMING
  • SDK Java SDK, Java 8 or later, Python 2.7.9 or later
PLATFORM OS
  • ATS AccuCollect
  • ATS Universal Command Set (UCS)
POWER
  • 5W Average, 12.95W Maximum
  • Optional 15W IEEE 802.3af-compliant Power over Ethernet (PoE)
  • Optional cell modem
ENVIRONMENT
  • Operation Temperature: -10˚ to 50˚C (14˚ to +122˚F)
  • Storage Temperature: -20˚ to 80˚C (-4˚ to +176˚F)
DIMMENSIONS
  • 26.4 cm x 23.4 cm x 8.6 cm (10.4” x 9,21 x 3.39”)
ENCLOSURE
  • Plastic housing
CERTIFICATIONS
  • CE Mark, FCC Part 15 Class A
ACCESSORIES
  • Smartcard readers – contactless (HID® Prox, Mifare™, iClass®)
  • Optional external reader – Wiegand compatible & USB
  • WIFI 802.11 a,b,g,n; 2.4 GHz only; DHCP & Static; WPA2
