employee time clock

PeoplePoint Premium™

Employee Time and Attendance System with a New Level of Interaction

The PeoplePoint Premium time and attendance system offers a new level of interaction for employee self-service applications. The 10.1” widescreen touch display makes it easy to navigate work and vacation schedules. The terminal also supports training videos, video chats, custom content, and other web-based applications. These capabilities are delivered through PeoplePoint Premium’s rich graphics, speakers, and camera.

  • 10.1” Widescreen Touch Display
  • Speakers with maximum volume, up to 83db at 40” (1 meter) distance
  • Wide Angle Camera.  Sensitivity range: from 125 lux to 5000 lux; Resolution 640×480
  • Optional Microphone
  • eMMC – 16GByte Storage
  • Optional – Biometric Suprema or Lumidigm® Reader
  • OS Flexibility: Supports Linux  / Android
  • Programming Languages Include: Java, Python, HTML and Android studio
  • High Performance Processor / iMX 6 Quad Core
>> Request a TimeCom Demo <<
>> Download Product Specs <<

PeoplePoint Premium Specifications

SPECIFICATION DESCRIPTION
DISPLAY
  • 10.1″ TFT Capacitive Touch, 16:10 Aspect Ratio, 1280 x 800 Resolution
PROCESSOR
  • Freescale i.MX6 Quad Core
MEMORY
  • 2GB DDR3 RAM
  • 512MB Flash
MASS STORAGE
  • Non-removable eMMC
  • 16 GB of which 5.6 MB are user available
CLOCK
  • Battery-backed real-time clock, 12- or 24-hour format (quartz precision)
KEYPAD
  • 20-key tactile, 4×5 matrix
    • Numeric keypad 0-9
    • Eight software-defined function keys
    • Clear/Enter keys
  • Customizable overlay allows for unique graphic options
PROGRAMMING
  • Linux with Java™/ Python, Web Services/ HTML
  • Android-based with Android Studio, web services HTML5
APPLICATION SOFTWARE
  • ATS Accu-Collect- Configurable punch workflows and backend communication interface (on Linux)
DIAGNOSTICS
  • On-board and remote diagnostics capability
INTERFACE
  • Standard 10/100/1000 BASE-T Ethernet
  • Optional internal 3G cellular modem
  • Internal USB port
  • Optional 4-Port Usb Hub
ENCLOSURE
  • PC/ABS
POWER
  • 12 VDC (nominal) 2A, 24W maximum
  • Optional uninterruptible power supply with charger
  • Optional IEEE 802.3/at-compliant POE Module
ENVIRONMENT
  • Operation Temperature: 0˚ to 50˚C (32˚ to +122˚F)
  • Storage Temperature: -20˚ to 80˚C (-4˚ to +176˚F)
DIMENSIONS
  • H 32.4cm x W 30.73cm x D 10.16cm (H 12.75” x W 12.1” x D 4”)
CERTIFICATIONS
  • CE Mark, FCC Part 15 Class A
ACCESSORIES
  • Biometric readers – 1:1 and 1:n – fingerscan and multispectral
  • Integrated visible or infrared barcode readers
  • Integrated magnetic stripe readers
  • Smartcard readers – contactless (Mifare™, iClass®, Marin)
  • Integrated proximity readers – HID Prox / Wiegand compatible
  • Dry-contact relay modules Dual form C (2A / 48V)
